20mm-110mm Glassfiber PPR Pipe Making Machine / PPR Pipe Production Line / PPR Tube Machine

Product Categories

Zhangjiagang Langbo Machinery Co. Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

20mm-110mm Glassfiber PPR Pipe Making Machine / PPR Pipe Production Line / PPR Tube Machine

Brand Name : LB

Model Number : LB

Certification : CE / ISO

Place of Origin : ZHANGJIAGANG, JIANGSU

MOQ : 1 SET

Price : 20000USD-30000USD

Payment Terms : L/C, T/T,

Supply Ability : 15 SETS PER MONTH

Delivery Time : 45 WORKING DAYS

Packaging Details : NORMAL PACKAGE

Production Name : PPR Glassfiber PPR Pipe Production Machine

Pipe Size : 20-110mm; 3 layer

Extruder Capacity : 350kgs/h for inner &outer +180kgs/h middle GF

Die head : 3 layer co-extrusion with two extruders

Production speed : 12m/min; 20m/min; 28m/min

Control system : SIEMENS PLC with remote control system

Warranty : 2 Years

Screw and barrel : Single screw

Motor : SIEMENS

Extruder Model : 6533

Contact Now

20mm-110mm Glassfiber PPR Pipe Making Machine/PPR Pipe Production Line/PPR Tube Machine

APPLICATIONS OF MULTI-LAYER PIPE PRODUCTION LINE

Multi-Layer pipes are produced by co-extrusion pipe line. The production line is a kind of special craft processes which can save the cost of raw material and make a series of pipes with functional features.

For Example, in order to save the cost of raw material, we can use the recycled material which is to be the middle layer to produce the PE thick wall pipes. For hot water supply pipes, the production line could not only have the PP-R Layer but also increase some other structure Layer including glass fiber, which attach the pipe to some excellent application features.

TECHNICAL PARAMETERS:

Pipe diameter(mm) 50,75,90,110,160 75,90,110,160,200,250

Extruder(for middle layer) 65/132 80/156

Extruder (for outer& inner layer) 65/132 or 55/120 65/132

Length of vacuum tank(mm) 6000 6000

Haul-offs machine 3claw 3claw

Cutting machine planetary cutting planetary cutting

SCOPE OF APPLICATION

1,Cold and hot drinking water pipe system
2,Industrial fluid transportation system
3,Feeding piping system in seaside facilities
4,Air-conditioning system
5,Agricultural irrigation system
6,Transportation internal piping system
